single Pearl milk tea straw packed machine

03-Series single pearl milk tea straw packing machine

   03-series single pear milk tea straw packing machine is a automatic machine for packing single  pear milk tea straw . Whole machine is composed of motor,gearing,automatic tensive winding sectin for thin film,straw feeding section,automatic sealing and cutting section,end product transporting section etc.The degree of the machine’s automatization is higher,and it’s packing rate  could replace more than 5 persons manualwork, and can save the material and personnel cost.

poly packing,forming a sack,stuffing,packing are done just once
the function of auto_count can facilitate the second packing
rapidity of packing can be adjust


Driving motor  0.75kw  Control by frequency converter     Power:220V
Production  capacity             90 ~100pcs/min
 Packing method                Three side sealing
 Wrapping material                BOPP film
 Width of wrapping   material                   Can be customized by client
Straw specifications                Diameter  Φ10~Φ14mm
               Length  180~220mm
Machine size                        1100×770×1200mm
 Weight                                300kg
